- Brand: EZ LYNK 3.0 - ELITE CUSTOM - FLO~PRO - JAMO.
- CONTACT US WITH QUESTIONS AT TECH@ELITEDIESELS.COM
- DO NOT UNINSTALL PARTS FROM TRUCK UNTIL YOU HAVE RECEIVED ALL EXHAUST PARTS AND TUNES.
- ALWAYS TUNE TRUCK BEFORE YOU INSTALL EXHAUST PARTS OR EGR DELETE KITS.
- EZLYNK DESCRIPTION AND VIDEO: CLICK HERE
- MUST HAVE A SMART PHONE TO DOWNLOAD TUNES.
- RETURN POLICY - SINCE THE EZLYNK IS VIN# SPECIFIC FOR CUSTOM TUNING, THERE ARE NO RETURNS OR REFUNDS.
- (((WARRANTY))) ALL PIPES/EXHAUST SYSTEMS, EGR KITS AND NONE ELECTRONIC PARTS COME WITH A STANDARD LIFETIME NONE PRO-RATED WARRANTY.
- (((WARRANTY))) TUNERS, TUNING SOFTWARE AND ELECTRONIC PARTS COME WITH A ONE YEAR STANDARD NONE PRO-RATED WARRANTY
- THIS TUNE PACKAGE INCLUDES CUSTOM ON AND OFF TUNES WITH EZLYNK 3.0 TUNER. (UNLESS ADDITIONAL OPTIONS ARE SELECTED)
***NOTICE***
IF YOU CHOSE TCM TRANSMISSION TUNING IT MUST MATCH THE ENGINE TUNES OF YOUR CHOICE.
WE CURRENTLY HAVE EZLYNK IN STOCK AND READY TO SHIP WITH THE LIFETIME AND 4 WEEK SUPPORT PACKS,
Vehicle Fitment
2010 - 2021 Dodge Ram 2500/3500/4500/5500 Cummins Diesel 6.7L.
2010 Dodge Cummins 6.7L
2011 Dodge Cummins 6.7L
2012 Dodge Cummins 6.7L
2013 Dodge Cummins 6.7L
2104 Dodge Cummins 6.7L
2015 Dodge Cummins 6.7L
2016 Dodge Cummins 6.7L
2107 Dodge Cummins 6.7L
2018 Dodge Cummins 6.7L
2019 Dodge Cummins 6.7L
2020 Dodge Cummins 6.7L
2021 Dodge Cummins 6.7L
2008 - 2019 Ford F250/350/450/550 ( Ford The 650/750 please contact us for more details ) Powerstroke Diesel 6.4L & 6.7L.
2008 Ford Powerstroke 6.4L
2009 Ford Powerstroke 6.4L
2010 Ford Powerstroke 6.4L
2011 Ford Powerstroke 6.7L
2012 Ford Powerstroke 6.7L
2013 Ford Powerstroke 6.7L
2014 Ford Powerstroke 6.7L
2015 Ford Powerstroke 6.7L
2016 Ford Powerstroke 6.7L
2017 Ford Powerstroke 6.7L
2018 Ford Powerstroke 6.7L
2019 Ford Powerstroke 6.7L
2011-2016 Chevy 2500/3500 Duramax Diesel 6.6L.
LML/LGH 2011 Chevy Duramax 6.6L
LML/LGH 2012 Chevy Duramax 6.6L
LML/LGH 2013 Chevy Duramax 6.6L
LML/LGH 2014 Chevy Duramax 6.6L
LML/LGH 2015 Chevy Duramax 6.6L
LML/LGH 2016 Chevy Duramax 6.6L
2016-2019 Nissan Titan XD Cummins 5.0 No Egr Kit Available for these titan trucks.
2016 Nissan Titan XD Cummins 5.0
2017 Nissan Titan XD Cummins 5.0
2018 Nissan Titan XD Cummins 5.0
2019 Nissan Titan XD Cummins 5.0
Tune Levels:
10-21 DODGE RAM 6.7L Hp levels.
Power Levels (Emissions Removed)
10-21 Ram 6.7L |
Level 1 |
Level 2 |
Level 3 |
Level 4 |
Level 5 |
|
+0HP |
+50HP |
+100HP |
+150HP |
+180HP |
Limited Support Package. Our limited support packs give you access to all tuning compatible with your vehicle for 4 weeks. This is convenient if you’re seeking a single tune to install on your vehicle. Once the 4 week expires the tune that is currently in your truck will remain. Upgrading to Full support will give you access to all tuning and software updates indefinitely.
Full Support Package offers unlimited flashes and basic tune revisions on ALL TUNES. You’ll receive automatic tune updates so that you can take advantage of the progress that we make and enjoy the timelessness of the EZ LYNK AutoAgent.
The SOTF Switch is needed to correctly run SOTF tunes. Without the switch installed, your tune will default to the lowest power level. Installing the switch will allow you to adjust power levels and maximize your vehicle’s performance instantly.
TCM Tuning will increase the line pressure in your transmission so it can keep up with all the added power your engine will be producing from the tunes. We highly recommend TCM tuning to anyone with a 68RFE that plans on running anything more than a tow tune. Please specify if you have any transmission modifications when ordering TCM Tuning!!
Year |
Tune 1 |
Tune 2 |
Tune 3 |
Tune 4 |
Tune 5 |
|
2008-2010 6.4L |
+0HP |
+60HP |
+120HP |
+180HP |
+240HP |
|
2011-2014 6.7L |
+0HP |
+50HP |
+100HP |
+150HP |
+200HP |
|
2015-2019 6.7L |
+0HP |
+50HP |
+100HP |
+150HP |
+200HP |
|
2016-2019 Nissan XD 5.0L Cummins Power Levels:
|
Level 1 |
Level 2 |
Level 3 |
Level 4 |
Level 5 |
|
0HP |
30HP |
60HP |
90HP |
120HP |
TUNE LEVELS
2018-2019 3.0L Powerstroke
Emissions |
Level 1 |
Level 2 |
Level 3 |
Level 4 |
Level 5 |
On |
0HP |
25HP |
60HP |
95HP |
N/A |
Off |
0HP |
25HP |
60HP |
95HP |
120HP |
Power Levels (Emissions Removed): 11-16 Chevy Duramax.
11-16 Chevy Duraamax |
Level 1 |
Level 2 |
Level 3 |
Level 4 |
Level 5 |
|
+0HP |
+50HP |
+100HP |
+150HP |
+200HP |
Additional Information:
Installation Steps
Living up to the brand name, EZ LYNK has made the installation process simple. We’ve broken down each step and provided some valuable information that will help you understand how your AutoAgent works.
Step One: Download & Install the AutoAgent App
The AutoAgent app is available for most smart devices. It requires iOS 8+ or Android 5+ to operate. You can download the iOS app here and the Android app here.
Step Two: Create an Account
From the AutoAgent app, select ‘create an account’. You will need to verify that your email address is valid upon creation. Dealers should always create an account for the end-user or use the account that the end-user has already created.
Step Three: Place Your Key in the ‘Run’ Position
Turn your key all the way over without starting the vehicle. This will boot your vehicle’s engine computer allowing the AutoAgent to communicate with it. If you have a push-to-start vehicle, you should press the Start button twice.
Step Four: Plug the AutoAgent into your OBD-II Port
With the key in the ‘Run’ position, plug your AutoAgent into your vehicle’s On-Board Diagnostics port. You can verify that it has booted correctly when you see that a blue and green light are illuminating from the device.
Step Five: Connect to your AutoAgent from your Smart Device
Navigate to the WiFi settings of your smart device and select the ‘EZLYNK_####’ network. A check mark will appear next to the network name when you have successfully connected. The AutoAgent 3 also allows you to connect via Bluetooth.
Step Six: Open the AutoAgent App
After you’ve successfully connected, you can navigate back to the AutoAgent app. You should now be able to see your vehicle gauges.
Step Seven: Lynk your Vehicle
When you purchase from Elite Diesels or an authorized dealer, your vehicle will be Auto Lynked. If your smart device has cellular data, you will notice that a message has appeared asking you to lynk the vehicle. Follow these prompts to connect your vehicle with your mechanic/technician. If your smart device does not have cellular data, you will need to connect to an internet available network and re-open the app to complete the lynking process.
Step Eight: Program Your Vehicle
After completing the lynking steps you are ready to flash your vehicle.
Navigate to > Vehicle > ECU Profiles. Here you can view the list of tunes or ECU profiles that are available to you.
Tap the button to download your desired ECU profile, followed by the ‘Install’ button to flash your vehicle. The app will guide you through the flashing procedure.
(When using a smart devices without cellular data you will need to switch to an internet available network to download the ECU profile, then back to the EZ LYNK network to install the ECU profile.)
Power Levels: 0hp up to 200hp+ Depending on truck and modifications.
Unlock cable - Includes required unlock cable for Nissan pickup trucks.
Diesel Particulate Filter (DPF) - The EZ Lynk is a DPF delete capable tuner. The DPF must be removed when installing the EZ Lynk. DPF Delete Pipe.
Catalytic Converter (CAT) - We recommend doing a CAT delete at the same time as the DPF delete.
Diesel Oxidation Catalyst (DOC) - If equipped, the DOC can be deleted.
Selective Catalytic Reduction (SCR) - If equipped, the SCR can be deleted.
Exhaust Gas Recirculation (EGR) - The EZ Lynk Auto Agent 3.0 will de-activate the EGR system. The EGR valve & EGR cooler can remain installed but unplug from any wiring harness or can be completely removed with an EGR delete kit. We recommend completely removing the EGR system but either option is available.
Diesel Exhaust Fluid (DEF) - 2013+ trucks in stock form require DEF. This will no longer be required when installing an EZ Lynk. The DEF tank can be removed completely or the wiring harness can just be unplugged.
Diagnostic Trouble Codes / Check Engine Light - The EZ Lynk Auto Agent 3.0 will prevent any emission related DTC’s or check engine light from setting. However, if some other issue comes up you will still be alerted. DTC’s can be checked / cleared.
Fuel Mileage - Expect to see a significant fuel mileage gains. If your DPF is plugged up your probably averaging about 13-14 mpg. More or less depending on the severity of the restriction. After installing the EZ Lynk and deleting the DPF/CAT expect to get a combined mileage of 18-19 mpg. Larger tires and poor driving habits will skew mileage downward.
Return Policy - Since the EZ Lynk is VIN specific custom tuning, there are no returns or refunds.
. Custom programming may take up to 24-48 Hours To Build Tunes. Once your order has been submitted it cannot be cancelled.
